Cash Teller Machine
Features:
– High speed processing ability, up to 12 notes per second
– Forgotten retraction function, retract the forgotten banknotes
– If the customer cancels the deposit, independent temporary storage mode allows the original currency returned to the customer.
– Self-counting function (all recycling cassettes can be calculated within 30 minutes)
– Double cash-out pocket design allows multiple application modes
– With sorting function
– Large quantity deposit function supports banknote non-stop feeding
– Large quantity withdraw function supports banknote removed in sequence from two pockets
– Up to 17,000 note capacity, with standard 1 retraction cassette, 4 recycling cassettes
– Both retraction and recycling cassette support one or two kinds of denomination
– Open and modular design, easy for maintenance
Description
| Complete Machine | |
| Item | Specification |
| Touch screen | 7” touchscreen |
| Safe sensor | Door-Heat-opt Seimic (Optional) |
| Safe lock | Static password lock, Key lock |
| PC | CPU: Intel i5, J1900/ RAM: 8GB,16GB / HD: SSD, 256GB |
| Interface: 2*LAN(minimum), 2*USB2.0(minimum), 2*USB 3.0, | |
| 3X RS232(optional), 1*VGA, 1*DVI, 1*HDMI, 2*AUDIO, 2*PS2 | |
| 4G (Optional) | |
| Indicator | Dual indicators on both left side and right side |
| Adjustable feet | Optional |
| Safe stanard | UL291 |
| Maintenance direction | Front, upper |
| Cover | Metal cover |
| Module | |
| Item | Specification |
| Cash | RMB, USD, EUR, REAL, RUPEE |
| Cash Size | Length120-180mm Width:60-85mm |
| Speed | Deposit:≥12/S Withdraw：≥12/S |
| Cash-in Slot Capacity | With shutter≥300 circulating notes (Equal to 600PCS new notes with thickness of 0.11mm） |
| Without Shutter≥500 circulating notes (Equal to 1100PCS new notes with thickness of 0.11mm） | |
| Cash-out Slot Capacity | ≥300 circulating notes（Equal to 600PCS new notes with thickness of 0.11mm） |
| Escrow | ≥300 circulating notes （Equal to 600PCS new notes with thickness of 0.11mm） |
| Cassette Capacity | Single denomination recycling cassette, acceptance cassette: ≥3400 new notes (thickness:0.11mm） |
| Dual denomination recycling cassette: Cassette1 ≥1800 new notes（thickness:0.11mm） | |
| Cassette2 ≥450 new notes （thickness:0.11mm） | |
| Cassette | 1 acceptance cassette, 4 recycling cassettes |
| Reliability | Lifetime: 10 years |
| MTBF ≥6000 hours | |
| MCBF(Withdraw) ≥20000 tractions | |
| MCBF(Deposit) ≥10000 tractions | |
| MTTR≤30 minutes | |
| Environment | Operation: 0°C～45°C,20%～90% RH（40°C) |
| Storage: -40°C～55°C，20%～93% RH（40°C) | |
